Ferdischreiter
A surviving Ferdischreiter
Overview
ManufacturerSchroeter Traktoren
Production1902–1921
DesignerFerdinand Schroeter
Body and chassis
ClassAgricultural tractor
Body styleOpen tractor
Powertrain
Engine0.8-litre single-cylinder air-cooled engine
Power outputApproximately 6 horsepower
TransmissionOne forward gear
Dimensions
Curb weight1,959 kilograms
Chronology
SuccessorWervelwerker

The Ferdischreiter was a Dutch agricultural tractor manufactured by Schroeter Traktoren from 1902 to 1921. Designed by Ferdinand Schroeter, it was one of the company's first tractors. It had an exposed belt drive and an unusual steering mechanism operated by pushing and pulling a control. The company built 35 Ferdischreiters, most of which had a heavy lead flywheel.

History

[edit | edit source]

Ferdinand Schroeter developed the Ferdischreiter in 1902, shortly after founding Schroeter Traktoren in Stolwijk. The company had taken over from the Schroeter Metaal en Lood Fabriek, which closed that year. Its first tractor was the Schedelmerg, followed by the Ferdischreiter later in 1902.[1]

The name Ferdischreiter came from Ferdi, a shortened form of Ferdinand, and the German word Schreiter, meaning strider. Workers originally used the name in the workshop because of the tractor's rough movement over uneven ground. At low speeds, the machine appeared to step forward as it moved. The name was later adopted for the model.

Schroeter Traktoren built the Ferdischreiter in small batches. Ferdinand made minor changes to the fittings and mounting positions of mechanical parts over the years, but kept the original design. Production ended in 1921 when the company introduced the Wervelwerker.[2]

Design

[edit | edit source]

The Ferdischreiter had a 0.8-litre single-cylinder air-cooled engine producing approximately 6 horsepower (4.5 kW). The engine ran at low speeds and was designed for pulling farm equipment. Power passed through an exposed belt on the right side of the tractor, between the engine and flywheel assembly. The transmission had one forward gear, with a maximum speed of approximately 15 km/h. Its speed depended on the engine's revolutions and the load it was pulling.

Most Ferdischreiters were fitted with a large lead flywheel on the right side. It kept the engine turning steadily between power strokes and also served as the starting mechanism. The driver started the engine by standing beside the tractor and spinning the flywheel by hand until the engine began running.

The use of lead came from the former Schroeter Metaal en Lood Fabriek. Other members of the Schroeter family preferred lead flywheels despite their weight and limited practical advantages. Lead was also soft enough to deform under repeated mechanical stress, which could leave the flywheel unbalanced and cause vibration. A few Ferdischreiters were fitted with cast-iron flywheels to avoid these problems.

The tractor weighed 1,959 kilograms. Much of this came from its steel frame and engine block, together with the heavy flywheel. The front axle and rear running gear were also heavily built, giving the tractor enough weight and traction for pulling small trailers over uneven ground.

Steering

[edit | edit source]

The driver operated the steering through a control positioned in front of the seat. Pushing it forwards or pulling it backwards moved a geared linkage attached to the front steering assembly. The control required considerable physical effort, especially on uneven ground. The steering parts were exposed and could be seen moving while the tractor was being driven.

A small battery powered a single lamp, which provided limited light for working around farmyards and barns after dark.

Mechanical problems

[edit | edit source]

One of the Ferdischreiter's main mechanical problems was caused by the position of its front steering assembly. An axle on the right side frequently struck the belt between the engine and flywheel. The contact wore down the belt, which needed regular adjustment and sometimes had to be replaced.

Later Ferdischreiters had slightly different mounting positions and spacing around the affected parts. The steering mechanism itself remained unchanged.

The tractor's open construction made repairs fairly simple. Farmers could reach the engine and belt directly, while mechanics could inspect the flywheel and front axle without removing body panels.

Agricultural use

[edit | edit source]

The Ferdischreiter was mainly used on smaller farms. It pulled trailers around farmyards and transported materials over short distances. Farmers also used it for light field work where its low gearing provided enough pulling power.

The tractor was generally kept near barns or workshops, where its exposed mechanical parts could be inspected and adjusted. Its low speed limited longer journeys, and the steering mechanism made frequent turns tiring for the driver.

Production and surviving examples

[edit | edit source]

Schroeter Traktoren manufactured 35 Ferdischreiters between 1902 and 1921, an average of 1.75 tractors per year over the 20 calendar years of production.

Six Ferdischreiters are known to survive.
